The radio photoelectric cell is used with the Protimer stopwatch or the Elite decoder.
Radio communication allows for easy installation. The transmitting power is 500 mW which allows visual distances of 2 km to be reached.
It is also possible to use a wired connection to connect the cell.
The infrared beam has a range of 25 m with a reflector. It is possible to use 2 photoelectric cells (a transmitter and a receiver) to achieve a range of 40m. The 3rd optic allows you to easily check the alignment of the photoelectric cell.
An internal lithium ion battery ensures 24 hours of autonomy.
The configuration of the photoelectric cell is accessible via a menu on the rear panel.
Features
- Radio or wired
- Infrared beam range:
25m with reflector
40m with another cell - Transmitting power 500 mW
- Lithium-ion battery (24h autonomy)
- Temperature range: -20 to 55°C (-4 to 131°F)
- Dimensions: 190 x 100 x 41 mm (7.5 x 3.9 x 1.6 in)
Connections
- 5 VDC charger
- 1 wired output
